1280x1024 Termal + 4MP 60x Optik Zoom Bias - Spectrum Load Tetal Network Tetep
|
Model |
Sg - PTZ4060NIO2 -12T50350 |
Sg - PTZ4060NIO2 -12T25225 |
||||
|
Termal |
||||||
|
Sensor |
Sensor gambar |
MicroBolometer VOX sing ora dilacak |
||||
|
Resolusi |
1280 × 1024 |
|||||
|
Ukuran Pixel |
12μm |
|||||
|
Range Spectral |
8 ~ 14μm |
|||||
|
Netd |
≤50mk @ 25 ℃, f # 1.0 |
|||||
|
Lensa |
Dawane fokus |
Lensa berita motor 50 ~ 350mm |
25 ~ 225mm lensa motor |
|||
|
Apenture |
F0.95 ~ f1.4 |
F1.0 ~ F1.5 |
||||
|
Bidang tampilan |
17.5 ° × 14,0 ° ° °.0 ° 2.0 ° (W ~ T) |
34.2 ° × 27.6 ° ° 3.9 ° × 3.1 ° (W ~ T) |
||||
|
Zoom optik |
7x |
9x |
||||
|
Zoom digital |
4x |
4x |
||||
|
Tingkat Perlindhungan |
IP6ROOFOF kanggo kaca pertama lensa. |
|||||
|
Video |
Kompresi |
H.265 / H.264 / H.264H |
||||
|
Snapshot |
Jpeg |
|||||
|
Werna Pseudo |
Dhukungan: Panas Panas, Putih Panas, Pelangi 1, Pelangi, Pelangi 2, Fusion, Bluish Abang, Amber, Artik, Tint |
|||||
|
Aliran |
Aliran utama: 25fps @ (1280 × 1024) Sub stream: 25fps @ (640 × 512), 25fps @ (352 × 288) |
|||||
|
Jaringan |
Protokol jaringan |
IPv4 / IPv6, http, https, qos, ftp, smtp, upnp, upnp, dns, ddn, rtp, tcp, pppoe, 802.1x, filter IP |
||||
|
Interoperabilitas |
Gambar OnvIF, Open API, SDK |
|||||
|
Max. Sambungan |
20 |
|||||
|
Intelijen |
Acara normal |
Deteksi gerakan, deteksi audio, konflik alamat IP, akses ilegal, anomalia panyimpenan |
||||
|
IVS Fungsi |
Dhukungan fungsi cerdas:TripWire,Deteksi pager, intrusi, Deteksi Pemaruan. |
|||||
|
Deteksi geni |
Dhukungan |
|||||
|
Kapabilitas panyimpenan |
Kertu SD mikro, nganti 256g |
|||||
|
Visible |
||||||
|
Sensor |
Sensor gambar |
1 / 1.8 "Sony Starvis Starvis Progresif Scan Cmos |
||||
|
Piksel sing efektif |
Kira-kira. 4.17 megapiksel |
|||||
|
Lensa |
Dawane fokus |
20mm ~ 1200mm, zoom optik 60x |
||||
|
Apenture |
F2.92 ~ F11.37 |
|||||
|
Bidang tampilan |
H: 22.06 ° ~ 0.37 °, V: 12.51 ° ~ 0.21 °, D: 25.21 ° ~ 0,43 ° |
|||||
|
Jarak fokus jarak |
2m ~ 50m (sudhut ~) |
|||||
|
Kecepatan Zoom |
<10s (optik wide ~ tele) |
|||||
|
Dori jarak (Manungsa) |
Ndeteksi |
Mirsani |
Ngerteni |
Ngenali |
||
|
16,650m |
6,607m |
3,330m |
1,665m |
|||
|
Video |
Kompresi |
H.265 / H.264B / H.264m / H.264.H / Mjpeg |
||||
|
Kapabilitas streaming |
3 lepen |
|||||
|
Resolusi |
Aliran utama: 50 / 60fps @ 2688 × 1520; 50 / 60fps @ 1920 × 1080; 50 / 60fps @ 1280 × 720 Sub stream1: 50 / 60fps @ 704 × 576; 50 / 60fps @ 352 × 288; Sub stream2: 50 / 60fps @ 1920 × 1280; 50 / 60fps @ 1280 × 720; 50 / 60fps @ 704 × 576 |
|||||
|
Tingkat bit video |
32Kbps ~ 16MBPS |
|||||
|
Audio |
AAC (8 / 16kHz) / mp2l2 (16kHz) |
|||||
|
Jaringan |
Protokol jaringan |
IPv4, IPv6, http, http, tcp, tcp, rtsp, rtc, arp, ftp, icp, qp, qp, qp, qp, qp, qp, qp, qp, qp, qp, qp, qp, qp, qp, qp, qp, qp, qp |
||||
|
Api |
Onvif, http api, sdk |
|||||
|
Browser web |
Yaiku, pinggiran, firefox, krom |
|||||
|
Pangguna |
Nganti 20 pangguna, 2 level: Administrator, pangguna |
|||||
|
Panyimpen |
SD Micro SD / SDHC / SDHC / SDXC (nganti 1TB) Storage Edge, FTP, NAS |
|||||
|
Multicast |
Dhukungan |
|||||
|
Acara Umum |
Gerak, Tamper, Kertu SD, Jaringan |
|||||
|
IVs |
Tripwire, deteksi pager, intrusion, obyek sing ditinggalake, cepet - obah, deteksi parkir, deteksi pemilihan. |
|||||
|
Bedane target |
Manungsa / kendharaan |
|||||
|
S / N Rasio |
≥55db |
|||||
|
Pencerakan Paling Dhuwur |
Werna: 0,05lux / F2.92; B / W: 0.005lux / F2.92 |
|||||
|
Pengurangan swara |
Suda Noise 2D / 3D / AI |
|||||
|
Mode cahya |
Auto, Bukten Bukten, prioritas rana, entuk prioritas, manual |
|||||
|
Ganti rugi cahya |
Dhukungan |
|||||
|
Kacepetan rana |
1/ 1 ~ 1 / 30000s |
|||||
|
Blc |
Dhukungan |
|||||
|
Hlc |
Dhukungan |
|||||
|
WDR |
Dhukungan |
|||||
|
Imbangan putih |
Otomatis, manual, njero ruangan, ruangan, ATW, Sodium Lampu, lampu lampu, alam, siji push |
|||||
|
Awan / wengi |
ICR (Auto / Manual) |
|||||
|
Mode Fokus |
Otomatis, Manual, Semi Otomatis, Siji Push AF |
|||||
|
Elektronik Defog |
Dhukungan |
|||||
|
Optik Defog |
Dhukungan, 750nm ~ 1100NM saluran optik |
|||||
|
Pengurangan Haze Panas |
Dhukungan |
|||||
|
Flip |
Dhukungan |
|||||
|
EIS |
Dhukungan |
|||||
|
OIS (Stabilisasi gambar optik) |
Dhukungan (ON / OFF) |
|||||
|
Zoom digital |
16x |
|||||
|
Pan miring |
||||||
|
Pan / Range Tilt |
Panci: 360 ° muter; Miring: - 90 ° ° ° ~ + 90 ° |
|||||
|
Kacepetan panci |
Konfigurasi, Pan: 0,01 ° ~ 180 ° / s |
|||||
|
Kecepatan miring |
Konfigurasi, Pan: 0,01 ° ~ 100 ° / s |
|||||
|
Presisi Pra - posisi |
± 0,003 ° |
|||||
|
Akurasi posisi |
0,003 ° |
|||||
|
Résolusi kacepetan rotasi |
0.001 ° / s |
|||||
|
Preset |
256 |
|||||
|
Wisata |
8, nganti 32 prasetel saben wisata |
|||||
|
Scan |
5 |
|||||
|
Pola |
5 |
|||||
|
Taman |
Pratet / Wisata / Scan / Pola |
|||||
|
Tugas sing dijadwal |
Pratet / Wisata / Scan / Pola |
|||||
|
Power - OFF MEMORY |
Dhukungan |
|||||
|
Posisi Snap |
Dhukungan |
|||||
|
Proporsi p / t kanggo zoom |
Dhukungan |
|||||
|
Mesin pemanas / penggemar |
Integrasi, otomatis / manual |
|||||
|
Wiper |
Integrasi, manual / dijadwal |
|||||
|
Antarmuka |
||||||
|
Antarmuka Daya |
Dhukungan, GND |
|||||
|
Ethernet |
1x RJ45 (10 / 100Mbps Self - port eternet adaptif) |
|||||
|
Audio i / o |
1/1 (kanggo kamera sing katon mung) |
|||||
|
Alarm i / O |
7/2 |
|||||
|
RS485 |
1, Ndhukung Pelco - D Protocol |
|||||
|
Umum |
||||||
|
Anti banyu |
IP66 |
|||||
|
Kekuwatan |
DC48, khas 30w, Max 180W |
|||||
|
Kelembapan |
<9 90%, Non - Konderat |
|||||
|
Suhu |
Kèndêl ingsun - 40 ℃ ~ + 60 ℃ / 22 ℉ ℉ ℉ 140 ℉ |
|||||
|
Ukuran (l * w * h) |
590mm * 835mm * 524.5mm |
|||||
|
Bobot |
Kira-kira. 88kg |
|||||
|
Nglindhungi |
Korosis - lapisan lapisan lapisan klasifikasi: astm b117 / iso.9227 (2000 jam) TVS 6000V, Perlindhungan Surge, Perlindhungan Transsiing Voltage |
|||||
